Overview

PolyScience offers almost 50 different solutions for your laboratory's liquid heating needs - from a simple immersion circulator to economical open bath systems to full-featured circulating baths with ramp and soak capability. Typical applications include warming of reagents and culture media, thawing or tempering samples, biological incubation, cell culture, enzyme assays or controlling the temperature of laboratory equipment such as chromotography columns, viscometers and densitometers.

Feature

• Working temperatures from ambient 10° to 200°C
• Temperature stabilities to ±0.005°C
• Four controller types with large, intuitive displays and multiple communication options
• Large bath openings and easy to clean surfaces
• Swivel 180™ Rotating Controllers
• LidDock™ Lid Stowing System
• DuraTop™ Chemical Resistant Deck

PolyScience Refrigerated/Heated Circulators come with the following accessories:

• Reservoir cover
• Bypass tubing
• Male inlet and outlet adapters for 3/8, 1/4, and 3/16" (.95, .63, and .47 cm) tubing
• 6' (1.83m) standard grounded electrical cord

Controller Comparison

Specifications and features for the PolyScience Integrated Heated Baths vary based on the controller chosen.  Some key specifications are in the table below, and additional features for each controller are listed below the table.

*DIN 12876-1 Class III devices are rated for use with flammable liquids.  DIN 12876-1 Class I devices may be used with non-flammable liquids only.

AP Controller

Advanced Programmable Features

• Time/temperature programming (ten 100-step programs)
• Intuitive 4.3” (10.9 cm) SmartTouch™ display
• 6 languages: French, German, Spanish, Chinese, Arabic, English
• Variable speed pump with open- and closed-loop external circulation capability
• Swivel 180™ Rotating Controller
• On-board connectivity: USB-A & B, Ethernet, RS232/485, and external temperature probe
• Event scheduling (time & date) with real-time clock
• Review temperature trends for up to 10 days
• Multiple selectable “home” screens
• On-screen help
• Automatic and/or user-adjustable performance optimization
• 5-point calibration capability

AD Controller

Advanced Digital Features

• Intuitive 3.75” (9.5 cm) display with touch-pad control
• 4 languages: French, German, Spanish, English
• Swivel 180™ Rotating Controller
• On-board connectivity: USB-A & B, Ethernet, RS232/485, and external temperature probe
• On-screen prompts
• Automatic performance optimization and specific heat tuning
• Single-point calibration capability

SD Controller

Standard Digital Features

• Large, universal icon and English display
• Swivel 180™ Rotating Controller
• On-board connectivity: RS232 serial output
• On-screen prompts
• Automatic performance optimization
• Single-point calibration capability

MX Controller

Economy MX Features

• Large, universal icon and English display
• On-screen prompts
• Single-point calibration capability

Please note: PolyScience circulating baths are manufactured at the time the order is placed and have a 2-3 week lead time.

Key Attributes

Manufacturer specifications

FAQ

I would like to perform a heating / cooling program where the temperature ramps from one set point to another over time. Are the PolyScience 15 Liter Integrated Heated Baths capable of this?

That depends on the controller used. Only the Advanced Programmable and Performance Programmable controllers can be programmed to perform ramps.

It is possible to have the circulation on without any temperature control being on?

No. If the circulation is on, then a temperature setting must be selected.
