- Programming via web browser.
- Programmable output protocol.
- Programmable up to 3 shifts.
The NC377 Voltage Interface (Paging Interface Adapter) is used with TekTone® NC110, NC150 and NC200 hardwired nurse call systems to add radio pocket paging. The interface is connected between the nurse call system and the radio pocket pager transmitter. The NC377 Voltage Interface detects calls, determines priority, and then sends information to the NC365B or NC369 Paging Transmitter. Program call points so that calls are sent to the appropriate pager. Information sent includes call type and room number. The pager stamps )the time and date.
The NC377 Voltage Interface may also be used to connect a non-TekTone system or an NC110, NC150 or NC200 hard-wired nurse call system to TekTone's Tek-ALERT® Integration Manager. The interface is connected between the monitored system and the LS601 serial to IP converter. The NC377 Voltage Interface detects call signals from the monitored system and sends information to the Tek-ALERT system via an LS601 Serial to IP Converter. To determine which settings to use for this purpose, please see the PDF of the manual located on the CD labeled NC377 Paging Interface Adapter Extended Manual.Main Features- Programming via web browser.
- Programmable output protocol.
- Programmable up to 3 shifts.
- Global Pager ID; two available.
- System Health Check and Time Period (2, 5, 15 minutes; 1 or 2 hours).
- 576 total contact inputs.
- Storage: Log all alarms. All logs stored in 24-hour files.
- Reports: Database, by Room, Type of Call, Elapsed Time.
- FCC Part 15, UL® 1069 listed, CSA and RoHS compliant
General InformationName: TekTone NC377/32 Voltage Interface for Tek-ALERT Alert Integration Manager, TekTone Sound & Signal Mfg., Inc, TekToneCategory: TekTone, Communications, Nurse Call Systems, Master Stations
